AI Video Analytics on Edge
Our Smart VCA (Video Content Analysis) suite is the next-generation video analytics solution running directly on WESTCOM cameras for superior security applications. This powerful on-board suite includes comprehensive detection capabilities such as Intrusion, Loitering, and Line Crossing, alongside advanced features like Running and Crowd Detection, Face Detection, Unattended Object Detection, and Missing Object Detection.

Deep Learning Technology
WESTCOM's VCA is powered by a deep learning AI engine, delivering significantly advanced accuracy in people detection compared to traditional rule-based designs. Leveraging our vast surveillance experience and extensive image databases, we developed a neural-network powered engine trained specifically to recognize the human form instantly. Since people are the primary focus of most surveillance, this feature allows users to quickly configure installations. People-detection ensures that only human activities trigger events, effectively ignoring swaying vegetation, vehicles, and animals. This drastically reduces false alarms and minimizes the time and effort needed for camera configuration.


Complete Video Security Solution with WESTCOM
Manage all devices and accounts from a single, unified platform. This gives you accurate event monitoring and intuitive security system operation—including video investigation—no matter your location.
AI adoption in security is frequently hindered by challenging installation and configuration processes, resulting in slower implementation for installers and a higher learning curve for end-users. Deep Search is designed to address this complexity head-on. It simplifies the entire process and provides automated investigation features that quickly transform user judgment into confident, efficient action.
Thermal Module | |
Image Sensor | Vanadium Oxide Uncooled Focal Plane Arrays |
Resolution | Sensor is 640×512. Image can be scaled up to 1280×1024 |
Pixel Pitch | 12 µm |
NETD | ≤ 40mK |
Spectral Range | 8 to 14 µm |
Focus Control | Fixed lens (Focus-Free) |
Focal Length | 9 mm, 15 mm, 25 mm, 35 mm, 50 mm |
Aperture | F1.0 |
Field of View (FOV) | 9 mm, H: 48°, V: 38° 15 mm, H: 29°, V: 23° 25 mm, H: 17°, V: 14° 35 mm, H: 12°, V: 10° 50 mm, H: 8°, V: 7° |
Intelligent Analytics | |
Smart Detection | Human and Vehicle detection, Fire point detection, and Smoking detection. |
Intelligent Analysis | Intrusion, Single line crossing, Double line crossing, Loitering, Wrong-way detection, Enter area, and Leave area (these functions support accurate detection of human / vehicles) |
People counting | Support |
Thermal Function | |
Temperature Range | -20°C to 150°C (-4°F to 302°F) |
Accuracy | ±2°C / ±2% |
Temperature Detection | 3 temperature measurement rule types, 20 rules in total, 1 full screen, 19 others (spot, areas, line). |
Temperature Alarm | Temperature difference alarm, Threshold alarm, Temperature rise alarm |
Temperature Display | Display in the lower left corner; follow the cursor display of the highest temperature, lowest temperature or average temperature |
Response Time | ≤ 30ms |
Video and Audio | |
Main Stream | 1280×1024, 1280×720, 640×512 @25fps |
Sub Stream | D1, CIF @25fps |
Bit Rate Control | CBR/VBR |
Video Compression | H.265, H.264 |
Bit Rate | Mainstream: 100 Kbps to 8 Mbps Sub stream: 100 Kbps to 6 Mbps |
Region of Interest | Off/On (8 Zone, Rectangle) |
Audio Compression | G.711 A-law, G.711 μ-law, PCM |
Audio Bit Rate | 64 Kbps (G.711), 128 Kbps (PCM) |
Image | |
Image Setting | Brightness, Contrast, Sharpness |
Mirror | Horizontal / Vertical / Horizontal + Vertical |
Pseudo-color Setting | Up to 17 colors (White-hot / Black-hot / Rainbow / Iron red / HSV /Bone / Cool / Copper / Fire-hot / Pink / Spring / Summer / Autumn / Winter / Jet / Flame / Rose -Bengal) |
FFC Control | Auto / Manual |
Noise Reduction | 2D/3D DNR |
OSD | Up to 8 OSD |
Privacy Masking | Up to 4 areas |
Event | |
Alarm Triggers | IVS, Temperature anomaly, Motion detection, Alarm Input, Disk alarm, Network alarm, Abnormal sound detection |
Event Actions | Alarm record, Alarm output, FTP upload, SMTP upload, Audible alarm output |
Network | |
Protocols | IPv4/IPv6, HTTP/HTTPS, DNS, DDNS, DHCP, PPPoE, RTSP/ RTCP/RTP, TCP/UDP, NTP, ARP, UPnP, FTP, SMTP, QoS, ICMP, IGMP, SMTP, 802.1x, SNMP, Multicast |
Interoperability | ONVIF (Profile S/T/G/M), SDK, CGI |
Max Concurrent Streams | 10 channels |
User/Host Level | 32+ users, 3 levels: Administrator, Operator, Media user |
Security | IP address filter, HTTPS, Illegal login lock, IEEE 802.1x |
Web Viewer | <IE11, Chrome, Firefox, Microsoft Edge |
Interface | |
Network Interface | 1 Ethernet (10/100 Base-T) RJ-45 Connector |
Audio Interface | 1ch Audio In, 1ch Audio Out |
Alarm Interface | 2ch Alarm In, 2ch Alarm Out |
BNC Interface | 1ch (CVBS output) |
Control Interface | 1ch RS-485 |
SD Card Slot | Built-in, up to 512 GB |
Reset Button | Support |
General | |
Language | English, Chinese, Traditional Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian, Japanese, Korean. Default: English |
Power Supply | 12 VDC / 24 VAC / PoE (802.3af) |
Power Consumption | Max 5 W |
Working Temperature/Humidity | -40°C to 60°C (-40°F to 140°F), Humidity: ≤90% RH (non-condensing) |
Operating Humidity | 0 to 90% RH |
Certifications | CE-EMC - EN 55032, EN IEC 61000-6-3, EN IEC 61000-3-2, EN 61000-3-3, EN 55035, EN 50130-4 FCC 47 CFR Part 15 Subpart B |
Ingress Protection | IP66 |
Material | Metal |
Dimensions | φ120.5 × 315.9 ~ 352.6 mm (φ4.74” × 12.44” ~ 13.88”) |
Net Weight | 1.7 kg (3.75 lb) with 9mm lens |
DRI Distance Table | |||||
Focal Length | 9 mm | 15 mm | 25 mm | 35 mm | 50 mm |
Detection Distance (Humans: 1.8×0.5m) | 375 m (1230.3 ft) | 625 m (2,050.5 ft) | 1,042 m (3,418.6 ft) | 1,458 m (4,783.5 ft) | 2,083 m (9,196.2 ft) |
Detection Distance (Vehicles: 4×1.5m) | 1,150 m (3,773 ft) | 1,917 m (6,289.3 ft) | 3,194 m (10,479 ft) | 4,472 m (14,672 ft) | 6,389 m (20,961 ft) |
Recognition Distance (Humans: 1.8×0.5m) | 94 m (308.4 ft) | 156 m (511.8 ft) | 260 m (853 ft) | 365 m (1,197.5 ft) | 521 m (1,709.3 ft) |
Recognition Distance (Vehicles: 4×1.5m) | 288 m (944.9 ft) | 479 m (1,571.5 ft) | 799 m (2,621.4 ft) | 1,118 m (3,668 ft) | 1,597 m (5,239.5 ft) |
Identification Distance (Humans: 1.8×0.5m) | 47 m (154.2 ft) | 78 m (255.9 ft) | 130 m (426.5 ft) | 182 m (597.1 ft) | 260 m (853 ft) |
Identification Range (Vehicles: 4×1.5m) | 144 m (472.4 ft) | 240 m (787.4 ft) | 399 m (1,309 ft) | 559 m (1,834 ft) | 799 m (2,621.4 ft) |
Smart Detection Range Table | |||||
Focal Length | 9 mm | 15 mm | 25 mm | 35 mm | 50 mm |
VCA Detection Distance (Human: 1.8 × 0.5 m) | 40 m (131.2 ft) | 65 m (213.3 ft) | 101 m (331.4 ft) | 160 m (524.9 ft) | 235 m (771 ft) |
VCA Detection Distance (Front/Rear of Vehicle: 4×1.5 m) | 65 m (213.3 ft) | 130 m (426.5 ft) | 230 m (754.6 ft) | 320 m (1,049.9 ft) | 400 m (1,312.3 ft) |
Temperature Measurement (Object: 1 × 1m) | 150 m (492.1 ft) | 250 m (820.2 ft) | 417 m (1,368.1 ft) | 583 m (1,912.7 ft) | 833 m (2,732.9 ft) |
Temperature Measurement (Object: 0.2 × 0.2m) | 30 m (94.4 ft) | 50 m (164 ft) | 83 m (272.3 ft) | 117 m (383.9 ft) | 167 m (547.9 ft) |
Fire Detection (Object: 1 × 1m) | 375 m (1,230.3 ft) | 625 m (2,050.5 ft) | 1,042 m (3,418.6 ft) | 1,458 m (4,783.5 ft) | 2,083 m (9,196.2 ft) |
Fire Detection (Object: 0.2 × 0.2m) | 75 m (246.1 ft) | 125 m (410.1 ft) | 208 m (682.4 ft) | 292 m (958 ft) | 417 m (1,368.1 ft) |
